HAAS VF-3 VERTICAL MACHINING CENTER

HAAS VF-3 VERTICAL MACHINING CENTER

Stock Number: 1099

HAAS VF-3

Age: 2001




Click to view larger photo

SpecificationDescription
TABLE WORKING SURFACE48" X 18"
TABLE LOAD CAPACITY1,750 LBS.
TABLE TRAVELS40" X 20" 25"

RAPID TRAVERSE RATE, ALL AXES1,400 IPM
SPINDLE NOSE TO TABLE4" - 29"
TOOL CHANGER ARM STYLE24 + 1
CHIP TO CHIP TOOL CHANGE2.2 SECONDS (AVG)
SPINDLE HORSEPOWER25 HP
SPINDLE SPEEDS RANGE7,500 RPM/ 2 SPEED GEAR BOX
SPINDLE TAPERCAT- 40
WAY SYSTEMLINEAR GUIDEWAY
OVERALL DIMENSIONS110" X 118" X 117"
APPROXIMATE WEIGHT - NET12,500 LBS.

Equipped With:
4TH AXIS DRIVE AND WIRING
RIGID TAPPING
CHIP AUGER
PROGRAMMABLE COOLANT NOZZLE
USER DEFINABLE MACROS
REMOTE JOG HANDLE
FLOPPY DRIVE
HIGH INTENSITY LIGHTING
VISUAL QUICK CODE
SPINDLE ORIENTATION
REMOTE JOG HANDWHEEL
COORDINATE ROTATION AND SCALING
