| Specification | Description |
|---|---|
| MAX SWING OVER BEDWAYS GAP CLOSED | 22" |
| MAX SWING THROUGH GAP | 47.5" |
| MAX SWING OVER THE CROSS SLIDE | 16" |
| MAX DISTANCE BETWEEN CENTERS BED CLOSED | 80" |
| MAX DISTANCE BETWEEN CENTERS BED EXTENDED | 120" |
| HOLE THROUGH SPINDLE | 2" |
| TAILSTOCK SPINDLE TRAVEL | 10" |
| TAILSTOCK SPINDLE DIAMETER | 6" |
| SPINDLE NOSE | D1-8 CAMLOCK |
| SPINDLE SPEEDS (27) | 4-1,000 RPM |
| THREADING LEADS (93) | 2 TO 36 TPI |
| FEEDS CHANGES (109) | .0034 TO .205 IPR |
| ELECTRICS (2 SPEED MOTOR) | 440/3/60 |
| HORSEPOWER | 7 1/2 / 15 HP |
| APPROXIMATE DIMENSIONS CLOSED (+ELECTRICAL CABINET) | 166' X 60' |
| APPROXIMATE MACHINE HEIGHT | 75" |
| APPROXIMATE WEIGHT | 12,500 LBS. |
