TAKISAWA NEX-110 10 CHUCK CNC TURNING CENTER WITH FANUC CONTROL

TAKISAWA NEX-110 10" CHUCK CNC TURNING CENTER WITH FANUC CONTROL

Stock Number: 1187

TAKISAWA NEX-110

Age: 2009

Condition: EXCELLENT

LESS THAN 700 ACTUAL HOURS MACHINE ONLY RAN OIL AS COOLANT


Click to view larger photo

SpecificationDescription
CHUCK / BAR DIAMETER10" / 2.5"
SWING OVER BED19.5"
CENTER DISTANCE33.25"
MAX TURNING DIAMETER15.75"
SPINDLE NOSEA2-8
SPINDLE SPEEDS - 2 RANGE GEAR BOX3,500 RPM
TOOL TURRET12 STATION
RAPID TRAVEL - Z866 IPM
RAPID TRAVEL - X708 IPM
TAILSTOCK5 MT / 5.88 STROKE
SPINDLE MOTOR25 HP
WEIGHT11,000 LBS.
DIMENSIONS (LESS CHIP CONVEYOR)112" x 71" x 71"
POWER35 KVA

Equipped With:
10" 3 JAW CHUCK (KITAGAWA B-210) - UNUSED IN BOX
FANUC 21iTB CNC WITH FLASH CARD & RS-232 PORT
PROGRAMMABLE QUILL TAILSTOCK
CHIP CONVEYOR - LIFT UP TYPE
BARFEED INTERFACE
12 STATION TURRET WITH TOOL BLOCKS
30 DEGREE SLANT BED DESIGN
2 RANGE AUTO SHIFT GEARED SPINDLE
60 GALLON COOLANT TANK
