| Specification | Description |
|---|---|
| TABLE WORKING SURFACE | 36" x 14" |
| TABLE LOAD CAPACITY | 1,500 LBS. |
| LONGITUDINAL TRAVEL (X-AXIS) | 30" |
| CROSS TRAVEL (Y-AXIS) | 16" |
| VERTICAL TRAVEL (Z-AXIS) | 20" |
| FEED RATES, ALL AXES | 833 IPM |
| RAPID TRAVERSE RATE, ALL AXES | 1,400 IPM |
| TOOL CHANGER ARM STYLE | 24 + 1 |
| SPINDLE HORSEPOWER | 30 HP |
| SPINDLE SPEEDS RANGE | 12,000 RPM/INLINE DIRECT DRIVE |
| SPINDLE TAPER | #40 BT |
| WAY SYSTEM | LINEAR GUIDEWAY |
| OVERALL DIMENSIONS | 88" x 92" x 104" H |
| APPROX WEIGHT - NET | 8,000 LBS. |
