| Specification | Description |
|---|---|
| TABLE WORKING SURFACE | 36" x 14" |
| TABLE LOAD CAPACITY | 2,000 LBS. |
| LONGITUDINAL TRAVEL (X-AXIS) | 30" |
| CROSS TRAVEL (Y-AXIS) | 16" |
| VERTICAL TRAVEL (Z-AXIS) | 20" |
| FEED RATES, ALL AXES | 0 - 500 IPM |
| RAPID TRAVERSE RATE, ALL AXES | 0 - 800 IPM |
| TOOL STORAGE CAPACITY | 20 CAROUSEL |
| SPINDLE HORSEPOWER | 10 HP |
| SPINDLE SPEEDS RANGE | 0-7500 RPM (2 RANGES) - GEARED |
| SPINDLE TAPER | #40 CT |
| WAY SYSTEM | LINEAR GUIDEWAY |
| OVERALL DIMENSIONS | 88" x 92" x 104" |
| APPROXIMATE WEIGHT - NET | 8,000 LBS. |
