KITAMURA BRIDGECENTER 8 DOUBLE COLUMN VERTICAL MACHINING CENTER

KITAMURA BRIDGECENTER 8 DOUBLE COLUMN VERTICAL MACHINING CENTER

Stock Number: 1004

KITAMURA BRIDGECENTER 8

Age: 1995




Click to view larger photo

SpecificationDescription
TABLE SIZE98.5" x 33.5"
TABLE LOAD CAPACITY6,600 LBS.
SPINDLE NOSE TO TABLE9.9" - 37.9"
X-AXIS TRAVEL80"
Y- AXIS TRAVEL42"
Z- AXIS TRAVEL28"
RAPID TRAVERSE RATE: X AXIS472 IPM
RAPID TRAVERSE RATE: Y AXIS472 IPM
RAPID TRAVERSE RATE: Z AXIS393 IPM
CUTTING FEED RATE0.00- 197 IPM
SPINDLE TAPERCAT-50
SPINDLE MOTOR- 30 MIN. RATING25HP
SPINDLE SPEEDS- 2 RANGE GEARED60-6000 RPM
TOOL CHANGER CAPACITY30 ARM ATC
TOOL CHANGE TIME (TOOL TO TOOL)6.7 SEC.
TOOL CHANGE TIME (CHIP TO CHIP)12 SEC.
WEIGHT37,400 LBS.

Equipped With:
FANUC 15M CNC CONTROL
RIGID TAPPING
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULL ENCLOSED SPLASH GUARDING
ALL AVAILABLE MANUALS
CHIP CONVEYER & DUAL CHIP AUGERS
SPINDLE CHILLER
SPINDLE REBUILT IN 2010
GLASS SCALES- ALL 3 AXIS

APPROX. 75 CAT- 50 TOOL HOLDERS AVAILABLE BY PIECE OR LOT
LYNDEX C50FH-ER32-205 FLEX HEAD WITH 360 ANGLE POSITIONING AND (10) ER- 32 COLLETS ($13,000 NEW)- ASKING PRICE: $8.750
4" THICK ALUMINUM SUB PLATE, AVAILABLE PER SEPERATE NEGOTIATION
